Examplary Mapping of Units of Measurement Based on Different Data Dictionaries This section provides a number of examples to illustrate how to model units of measurement using the given data specification template. Motivation The publicly avbailable dictionaries for units of measurements vary greatly in their modelling philosophy and scope. They do not only differ in the number of units they contain, but also in the number of descriptive attributes per unit. Not all dictionaries were created to be "machine interpretable". Some dictionaries are multi-lingual, some make use of extended UNICODE symbols. To accomodate the different sources for units the given data specification template for units of measurements is very flexible to use. The examples below provide an orientation on how to use that flexibility to map the information from the most prominent public dictionaries to the given data specification template. Examples The following modelling rules have been applied to the examples and are highly recommended: The attributes for an UoM should be consistent, i.e. they should all come from the same source, i.e. dictionary. It is counterproductive to mix sources, e.g. by providing an UNECE REC 20 ID, but using the definition from ECLASS. In case of discrepencies between the dictionaries the receiver of the model cannot resolve these conflicts and does not know which source has precedence. For the same reason the classificationSystemVersion should be consistent throughout an application. The units should not be mixed from different dictionary versions. The source that was actually used and verified for the units should be used as a modelling basis. E.g., if the source for the unit definition is a SAMM model then this model should be used consistently to fill the attributes. Even though the units in SAMM are based on UNECE REC 20, the UNECE dictionary should only be referenced if the modeller used this as the original source. It is good scientific practice to only cite the sources that were actually used and not the sources cited by sources. Sometimes a UoM is applicable for multiple quantities as denoted by the dictionaries. However, when used for quantifying a properties value, the appropriate quantity has to be selected. The tables below are read as follows: The first two columns, attribute and card, provide the respective attribute names and cardinality specified in this data specification template. The third column, mapping recommendation, provides the information on how to map a unit definition from the given dictionary to the respective AAS atribute. "-----" means that it is recommended to omit this optional attribute. [no recommendation] means that an entry has to be provided, but no general mapping rule can be provided. For simplicity reasons the examples are only provided in English language even if the respective attribute has a multilanguage datatype. ECLASS The modelling of UoM in ECLASS Basic and Advanced is similiar, but not identical, even though they are based on the same dataset. Some attributes are named differently and some attributes are only available in Basic or Advanced. Because the version of the property definition is coded into the IRDI/IRI of the property, it is not necessary to supply version information via the attribute classificationSystemVersion. However, it can be helpful to supply the catalogue version, because it is not possible to directly infer the catalogue version from the property version. Table 1. Mapping recommendation and examples for ECLASS Basic attribute (of data specification) card mapping recommendation Example 1 Example 2 Example 3 conceptDescription/id 1 IrdiUN of ECLASS unit [1] 0173-1#05-AAA480#005 https://api.eclass-cdp.com/0173-1-05-AAA480-003 0173-1#05-AAA793#002 preferredName 1 PreferredName of ECLASS unit millimetre millimetre Kilogramm^-1 symbol 1 ShortName of ECLASS unit mm mm 1/kg specificUnitID 0..1 Optional. Recommended to supply IRDI if IRI is provided as conceptDescription/id 0173-1#05-AAA480#003 definition 0..1 Definition of ECLASS unit 0,001-fold of the SI base unit metre 0,001-fold of the SI base unit metre reciprocal of the SI base unit kilogram preferredNameQuantity 0..1 NameOfDedicatedQuantity of ECLASS unit distance distance reciprocal mass quantityID 0..1 -----[2] classificationSystem 0..1 "ECLASS" ECLASS ECLASS ECLASS classificationSystemVersion 0..1 ECLASS version 15.0 14.0 10.0 Table 2. Mapping recommendation and examples for ECLASS Advanced attribute (of data specification) card mapping recommendation Example 1 Example 2 Example 3 conceptDescription/id 1 id of ECLASS unit [1] 0173-1#05-AAA480#005 https://api.eclass-cdp.com/0173-1-05-AAA480-003 0173-1#05-AAA793#002 preferredName 1 preferred_name of ECLASS unit millimetre millimetre Kilogramm^-1 symbol 1 short_name of ECLASS unit mm mm 1/kg specificUnitID 0..1 Optional. Recommended to supply IRDI if IRI is provided as conceptDescription/id 0173-1#05-AAA480#003 definition 0..1 definition of ECLASS unit 0,001-fold of the SI base unit metre 0,001-fold of the SI base unit metre reciprocal of the SI base unit kilogram preferredNameQuantity 0..1 QuantityReference/name of ECLASS unit distance distance reciprocal mass quantityID 0..1 QuantityReference/url of ECLASS unit 0173-1#Z4-BAJ199#002 https://api.eclass-cdp.com/0173-1-Z4-BAJ199-002 0173-1#Z4-AAB646#002 classificationSystem 0..1 "ECLASS" ECLASS ECLASS ECLASS classificationSystemVersion 0..1 ECLASS version 15.0 14.0 10.0 Figure 1. Snapshot of UoM descriptions in ECLASS Basic v16.0 (CSV-Export). Copyright by ECLASS e.V. Figure 2. Snapshot of UoM model in ECLASS Advanced v16.0 (XML-Export). Copyright by ECLASS e.V. IEC CDD IEC CDD and ECLASS can be mapped in a very similiar way. Because the IEC CDD has no version of the overall catalogue, the atribute classificationSystemVersion should be omitted. Table 3. Mapping recommendation and examples for IEC CDD attribute (of data specification) card mapping recommendation Example 1 Example 2 Example 3 conceptDescription/id 1 IRDI of IEC CDD unit 0112/2///62720#UAA862#001 https://cdd.iec.ch/cdd/iec62720/iec62720.nsf/Units/0112-2---62720%23UAB246 0112/2///62720#UAA017#002 preferredName 1 Preferred name of IEC CDD unit millimetre tex ohm symbol 1 Short name of IEC CDD unit mm tex Ω specificUnitID 0..1 Optional. Recommended to supply IRDI if IRI is provided as conceptDescription/id 0112/2///62720#UAB246#001 definition 0..1 Definition of IEC CDD unit unit for the indication of the linear mass of textile fibers and yarns SI derived unit with special name, for which the following relation applies: 1 Ω = 1 C·A⁻¹ = 1 S⁻¹ = 1 m²·kg¹·s⁻³·A⁻² preferredNameQuantity 0..1 Preferred name of the units quantity [3] length lineic mass electric resistance quantityID 0..1 IRDI of the units quantity [3] 0112/2///62720#UAD072#001 0112/2///62720#UAD079#001 0112/2///62720#UAD045#001 classificationSystem 0..1 "IEC CDD" IEC CDD IEC CDD IEC CDD classificationSystemVersion 0..1 "-----" Figure 3. View of the IEC CDD entry for the UoM tex. Copyright by the International Electronical Commision (IEC) Figure 4. View of the IEC CDD entry for the quantity "lineic mass". Copyright by the International Electronical Commision (IEC) UNECE In UNECE REC 20 and 21 the UoM are identified by a 2-3 letter code. While this code is unique within the specific list, it is not usable as a globally unique identifier. Therefore, a different identifier for the Concept Description has to be created. The examples illustrate different ways this could be achieved without giving a recommendation. Table 4. Mapping recommendation and examples for UNECE REC 20 attribute (of data specification) card mapping recommendation Example 1 Example 2 Example 3 conceptDescription/id 1 [no recommendation] uncefact:UNECERec20Code/MMT uncefact:rec20:kilocandela https://service.unece.org/trade/uncefact/vocabulary/rec20#page preferredName 1 Name of UNECE unit millimetre kilocandela page symbol 1 Representation symbol of UNECE unit mm kcd specificUnitID 0..1 Common code of UNECE unit MMT P33 ZP definition 0..1 Description of UNECE unit 1000-fold of the SI base unit candela. A unit of count defining the number of pages. preferredNameQuantity 0..1 Quantity of UNECE unit length luminous intensity quantityID 0..1 ----- classificationSystem 0..1 "UNECE Rec 20" UNECE Rec 20 UNECE Rec 20 UNECE Rec 20 classificationSystemVersion 0..1 Revision of UNECE REC 20 specification 17 16 17 Figure 5. View of exemplary UNECE REC 20 entries (Revision 17, Annex I). Copyright by the United Nations Economic Commission for Europe (UNECE) Table 5. Mapping recommendation and examples for UNECE REC 21 attribute (of data specification) card mapping recommendation Example 1 Example 2 Example 3 conceptDescription/id 1 [no recommendation] uncefact:UNECERec21Code:8A uncefact:rec21:piece https://service.unece.org/trade/uncefact/vocabulary/rec21/#Parcel preferredName 1 Name of UNECE unit Pallet, wooden Piece Parcel symbol 1 Name of UNECE unit Pallet, wooden Piece Parcel specificUnitID 0..1 Code of UNECE unit 8A PP PC definition 0..1 Description of UNECE unit A platform or open-ended box, made of wood, on which goods are retained for ease of mechanical handling during transport and storage. A loose or unpacked article. preferredNameQuantity 0..1 ----- quantityID 0..1 ----- classificationSystem 0..1 "UNECE Rec 21" UNECE Rec 21 UNECE Rec 21 UNECE Rec 21 classificationSystemVersion 0..1 Revision of UNECE REC 21 specification 12 11 12 Figure 6. View of exemplary UNECE REC 21 entries (Revision 12, Annexes V and VI). Copyright by United Nations Economic Commission for Europe BIPM (Bureau International des Poids et Mesures) / SI Digital Framework The BIPM focuses on the maintenance of the SI unit definitions, but also provides a definition of selected non-SI units and constants. In case of compound units the SI digital framework provides a method to generate the PID and semantic definition based on the SI units. However, in these cases a quantity, verbal description and full name are not provided. Table 6. Mapping recommendation and examples for the SI Digital Framework attribute (of data specification) card mapping recommendation Example 1 Example 2 Example 3 conceptDescription/id 1 PID of BIPM (compound) unit https://si-digital-framework.org/SI/units/ampere https://si-digital-framework.org/SI/units/dalton https://si-digital-framework.org/SI/units/millimetre preferredName 1 Unit or Compound unit of BIPM unit ampere dalton mm symbol 1 Symbol of BIPM unit A Da mm specificUnitID 0..1 ----- definition 0..1 Definition of BIPM unit The ampere, symbol A, is the SI unit of electric current. It is defined by taking the fixed numerical value of the elementary charge, e, to be 1.602176634x10^-19 when expressed in the unit C, which is equal to As, where the second is defined in terms of delta_v_cs. preferredNameQuantity 0..1 Quantity of the BIPM unit electric current mass quantityID 0..1 PID of the units quantity https://si-digital-framework.org/quantities/ELCU https://si-digital-framework.org/quantities/MASS classificationSystem 0..1 "BIPM" BIPM BIPM BIPM classificationSystemVersion 0..1 valid from 2019-05-20 Figure 7. View of the SI digital framework entry for the UoM Ampere. Copyright by BIPM Figure 8. View of the SI digital framework entry for the compound unit millimeter. Copyright by BIPM Other meta models Table 7. Mapping recommendation and examples for OPC UA attribute (of data specification) card mapping recommendation Example 1 Example 2 Example 3 conceptDescription/id 1 [no recommendation] http://www.opcfoundation.org/UA/units/5131860 http://www.opcfoundation.org/OPC34100/5720146 http://example-company/myCompanionSpec/UAA862 preferredName 1 description millimetre watt hour millimetre symbol 1 _displayName mm W·h mm specificUnitID 0..1 UnitID 5131860 5720146 UAA862 definition 0..1 ----- preferredNameQuantity 0..1 QuantityType length work length quantityID 0..1 ----- classificationSystem 0..1 namespaceUri http://www.opcfoundation.org/UA/units/un/cefact http://www.opcfoundation.org/UA/units/un/cefact http://www.opcfoundation.org/UA/units/ieccdd classificationSystemVersion 0..1 ----- Table 8. Mapping recommendation and examples for SAMM attribute (of data specification) card mapping recommendation Example 1 Example 2 conceptDescription/id 1 Unit element URN urn:samm:org.eclipse.esmf.samm:unit:2.2.0#degreeCelsius urn:samm:org.eclipse.esmf.samm:unit:2.2.0#percent preferredName 1 Preferred name of unit degreeCelsius percent symbol 1 symbol of unit °C % specificUnitID 0..1 ----- definition 0..1 description preferredNameQuantity 0..1 quantityKind/preferredName of unit temperature dimensionless quantityID 0..1 quantityKind of unit urn:samm:org.eclipse.esmf.samm:unit:2.2.0#temperature urn:samm:org.eclipse.esmf.samm:unit:2.2.0#dimensionless classificationSystem 0..1 "SAMM" SAMM SAMM classificationSystemVersion 0..1 Version 2.2 2.2 OPC UA uses the attribute namespaceUri to denote the classification system that has been used as the source for the UoM. The mapping of the attributes from that classification system is described in OPC UA Specification Part 8, Section 5.6.3.4. SAMM is based on UNECE Rec 20. The open source model is published as part of the Eclipse Semantic Modeling Framework (ESMF): https://eclipse-esmf.github.io/samm-specification/snapshot/units.html. When using mete models such as OPC UA or SAMM as the source for UoM, one has to be aware that this introduces "double-mapping". E.g. UNECE Rec 20 attributes are mapped to an OPC UA nodeset and then the attributes of that nodeset are mapped to the AAS metamodel. Such "double-mapping" often leads to a degradation of the information and should be avoided, if possible. However, as stated above, the source that was actually used and veryfied for the units should be used as a modelling basis. I.e., if and only if the source for the unit definition is a SAMM model then this model should be used consistently to fill the attributes of the Concept Description template even though SAMM is based on UNECE Rec 20. Examples of not recommended modelling approaches The following table lists some modelling mistakes that should be avoided. Table 9. Negative examples, i.e. discoraged moddeling approaches attribute (of data specification) card Example 1 Example 2 conceptDescription/id 1 0112/2///62720#UAA023#001 MMT preferredName 1 ångström millimetre symbol 0 Å mm specificUnitID 0..1 A11 MMT definition 0..1 0,000 000 000 1-fold of the SI base unit metre preferredNameQuantity 0..1 quantityID 0..1 classificationSystem 0..1 UNECE classificationSystemVersion 0..1 explanation Not recommended, because information from multiple sources is mixed "MMT" is not a unique ID and therefore not suitable as an identifier for conceptDescriptions. The omission of classificationSystem makes it impossible to use the original UNECE catalogue. 1. Alternatively ID can be provided as IRI starting with https://api.eclass-cdp.com/ 2. ECLASS basic does not provide the IDs of the quantities in its export 3. The quantities are listed under "Applicable list of units"
