IDTA 02045-1-0 Data Model for Asset Location Imprint Publisher Industrial Digital Twin Association Lyoner Strasse 18 60528 Frankfurt am Main Germany https://www.industrialdigitaltwin.org/ Version history Date Version Comment 2024-07-01 1.0 Release of the official Submodel template published by IDTA. 1. General 1.1. About this document This document is a part of a specification series. Each part specifies the contents of a Submodel template for the Asset Administration Shell (AAS). The AAS is described in [1], [2], [3] and [6]. First exemplary Submodel contents were described in [4], while the actual format of this document was derived by the "Administration Shell in Practice" [5]. The format aims to be very concise, giving only minimal necessary information for applying a Submodel template, while leaving deeper descriptions and specification of concepts, structures and mapping to the respective documents [1] to [6]. The target group of the specification are developers and editors of technical documentation and manufacturer information, which are describing assets in smart manufacturing by means of the Asset Administration Shell (AAS) and therefore need to create a Submodel instance with a hierarchy of SubmodelElements. This document especially details on the question, which SubmodelElements with which semantic identification shall be used for this purpose. 1.2. Scope of the Submodel The location of static or mobile objects (assets / goods / trackables) and, if applicable, the origin and destination of transport processes are naturally the most important information in transport and internal logistics. In the past, the postal address or a simple location description (e.g., hall B, aisle 3) or a GNSS coordinate (Global Navigation Satellite System, like GPS) was sufficient as location information for controlling logistics processes. With the increasing propagation of localization technologies such as Ultra-Wideband (UWB), BLE (Bluetooth Low Energy), RFID (Radio-Frequency Identification) and others, the continuous and precise tracking of objects becomes possible at reasonable costs. This opens up new possibilities for the automation, monitoring and analysis of goods flows and internal transportation tasks. It is also possible to measure masses of localization data for short distances within buildings, which is why the integration of a localization solution into warehouse systems or production lines is becoming increasingly popular. The systems for localization are usually referred to as real-time location systems (RTLS). Automated guided vehicles (AGVs) and autonomous transport robots with free navigation (AGVs) are also increasingly being used for internal transportation tasks. These are another driver for the use of localization technologies in companies. Further applications that require localization information are augmented reality or robotics applications in which in addition to the position the orientation of an object, the pose (6DoF), is of interest. This Submodel is not supporting 6DoF orientation information for now. Location data for assets are determined by different localization systems during the life cycle and even at the same point in time more than one system can deliver a location information. Today location data originate from a variety of non-interoperable systems, for which the data model for the localization information is not standardized. Since asset location data are generated and used by different systems, for different use cases, in different life cycle phases and by different organizations it makes particular sense to manage the location data in the AAS of an asset in the form of a standardized Submodel. 1.3. Relevant standards for the Submodel template One important standard that aims the interoperability in the field of localization is the open locating standard omlox. Omlox is hosted under the umbrella of the PROFIBUS & PROFINET International (PI) organization. Omlox includes also a specification for omlox compliant locating systems and corresponding APIs. More information can be found here: https://omlox.com/ https://www.profibus.com/technology/industrie-40/omlox-the-open-locating-standard In the attachment of this Submodel specification a mapping between the Submodel template and the omlox specification has been included. Further standards that have been considered regarding data for asset locations were: Open Geospatial Consortium (OGC) GeoPose 1.0 Data Exchange Standard ISO 19116:2019(en): Geographic information – positioning services World Geodetic System - 1984 (WGS-84) There is as well an initiative announced for an OPC UA Companion Specification “Global Positioning”. 2. Approach of the Submodel 2.1. Use cases and requirements The use cases for localization of mobile objects can be, for example, divided into use cases for track & trace, location-based automation, production execution and maintenance as well as material flow. With track & trace, for example, manual search efforts can be reduced, or transportation resource utilization can be determined based on movement analyses. Track means the determination of the current location and trace means the traceability of the shipment’s progress. This also includes applications for the traceability of the transport chain. Location-based automation means that events such as transport orders are triggered depending on the position of an object. When carrying out production or maintenance, location data helps to quickly reach the required components or machines to be serviced. The control and optimization of the material flow along the entire logistics chain using various transport and control systems is another field of application for localization technologies. In addition, also static objects have a permanent location that needs to be modeled. This can be used for example for use cases like navigation or as input for transportation orders where the origin and the destination can be linked to the Submodel instance. In many applications the origin and destination of an asset will play a role, e.g., for navigation or transport orders. Origin and destination can again be, in this case stationary, assets with this location data Submodel. The requirement was to reflect the wide rage of track & trace and localization use cases, the different needs on the quality of location data as well the different localization technologies with the Submodel template. Three structure elements ensure that the multitude of use cases can be supported. First the semantic structure of a geographically referenced region which is site, area (or building) and fence (see Figure 1) where a site can have one or more areas and/or fences assigned, and an area can have fences assigned. The second structure element are coordinate reference systems (CRS) which have so called “ground control points” for a mapping between a global geographic CRS and the local CRS which enables the coordinate transformation between all local coordinate reference systems. Site, area and fence can share the same coordinate reference system or just have their own. There is no need to model a site, area or fence in the AAS. At the minimum a position with an assigned CRS is sufficient. Figure 1. Structure elements of a geographically outlined region. A position (x,y,z-coordinate) is referenced to a CRS which will make it possible that an application based on the data of an AAS is able to determine the semantic relationships for a position, namely the assignment to one or more areas which the asset overlaps. An area can be of kind SITE, BUILDING or AREA_NOT_SPECIFIED. An area of kind AREA_NOT_SPECIFIED can be a virtual boundary (fence) that unlike a SITE or BUILDING is not representing a physical defined region. The main point of an area is to enable capturing entry and exit events of assets entering or leaving an area. An area is therefore an essential concept for location-automation Figure 2. Modelling of the height The modelling of the height is illustrated in Figure 2. For every CRS an ElevationReference has to be set which is defining the reference for the height (z-value of a position). 2.2. Structure and design decisions The structure of the Submodel template is shown in Figure 3. The SubmodelElementLists “Adresses” and “VisitedAreas” contain geographically referenced locations that an asset has visited during its lifecycle phases. Areas can be referenced to their address(es). VisitedAreas are regions that are defined wherein events are generated when an asset enters or leaves that area. The SubmodelCollection AssetTraces contains the records of events, namely the entry and exit of assets for VisitedAreas and with the SubmodelElementList LocationRecords the records of locations. The regions of VisitedAreas can be nested or overlap in arbitrary ways. In general, if the location of an asset lies within multiple overlapping regions, individual events for each of the regions are generated. The events are generated solely based of geographic relationship, e.g VisitedAreas have no direct relationship to another but may spatially overlap. For the SubmodelElementLists of the SubmodelElementCollection AssetTraces the order is relevant. The last entry is the latest event or location that has been recorded. Figure 3. Information structuring of the Submodel template “Data Model for Asset Location” 3. Approach of the Submodel 3.1. SubmodelElements of the Submodel template “Data Model for Asset Location” Table 1. SubmodelElements of the Submodel template “Data Model for Asset Location” idShort: AssetLocation Class: Submodel semanticId: https://admin-shell.io/idta/smt/assetlocation/1/0 Parent: - Explanation: Submodel for tracking & tracing of the location of an assets Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [SML] Addresses https://admin-shell.io/idta/sml/addresses/1/0 List with postal addresses where an object has been located [] 1 elements 0..1 [SML] CoordinateSystems https://admin-shell.io/idta/sml/coordinatesystems/1/0 List with information about different coordinate systems that have been used to determine the location of an asset [] 1 elements 0..1 [SML] VisitedAreas https://admin-shell.io/idta/sml/visitedareas/1/0 List with areas (e.g., sites, buildings, field warehouses) where an asset has been located or is located [] 1 elements 0..1 [SMC] AssetTraces https://admin-shell.io/idta/smc/assettraces/1/0 Collection of localization event records for sites, areas, fences and locations [] 4 elements 0..1 [SMC] AssetLocatingInformation https://admin-shell.io/idta/sml/assetlocatinginformation/1/0 Collection with additional information concerning the localization of an asset [] 4 elements 0..1 3.2. SubmodelElements of SML “Addresses” Table 2. SubmodelElements of SML “Addresses” idShort: Addresses Class: SubmodelElementList semanticId: https://admin-shell.io/idta/sml/addresses/1/0 Parent: AssetLocation Explanation: List with postal addresses where an object has been located Element details: orderRelevant=No, semanticIdListElement=[GlobalReference, 0173-1#01-ADR442#007], typeValueListElement=SubmodelElementCollection [SME type] idShort semanticId Description@en [valueType] example card. [SMC] Address00 0173-1#01-ADR442#007 Postal addresses where an object has been located [] 10 elements 3.3. SubmodelElements of SMC “Address” Table 3. SubmodelElements of SMC “Address” idShort: Address00 Class: SubmodelElementCollection semanticId: 0173-1#01-ADR442#007 Parent: Addresses Explanation: Postal addresses where an object has been located Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [Prop] AddressLine1 0173-1#02-AAO124#004 address line 1 [String] 0..1 [Prop] AddressLine2 0173-1#02-AAO125#004 address line 2 [String] 0..1 [Prop] AddressLine3 0173-1#02-AAO126#004 address line 3 [String] 0..1 [Prop] AddressOfAdditionalLink 0173-1#02-AAQ326#003 address of additional link [String] 0..1 [Prop] AddressRemarks 0173-1#02-AAO202#004 address remarks [String] 0..1 [Prop] NationalCode 0173-1#02-AAO134#003 national code [String] 0..1 [Prop] Statecounty 0173-1#02-AAO133#003 state/county [String] 0..1 [Prop] Citytown 0173-1#02-AAO132#003 city/town [String] 0..1 [Prop] Street 0173-1#02-AAO128#003 street [String] 0..1 [Prop] ZipCode 0173-1#02-AAO129#003 zip code [String] 0..1 3.4. SubmodelElements of SML “CoordinateSystems” Table 4. SubmodelElements of SML “CoordinateSystems” idShort: CoordinateSystems Class: SubmodelElementList semanticId: https://admin-shell.io/idta/sml/coordinatesystems/1/0 Parent: AssetLocation Explanation: List with information about different coordinate systems that have been used to determine the location of an asset Element details: orderRelevant=Yes, semanticIdListElement=[GlobalReference, https://admin-shell.io/idta/smc/coordinatesystemsrecord/1/0], typeValueListElement=SubmodelElementCollection [SME type] idShort semanticId Description@en [valueType] example card. [SMC] CoordinateSystem00 https://admin-shell.io/idta/smc/coordinatesystemsrecord/1/0 Coordinate reference system (CRS) record [] 6 elements 3.5. SubmodelElements of SMC “CoordinateSystemsRecord” Table 5. SubmodelElements of SMC “CoordinateSystemsRecord” idShort: CoordinateSystem00 Class: SubmodelElementCollection semanticId: https://admin-shell.io/idta/smc/coordinatesystemsrecord/1/0 Parent: CoordinateSystems Explanation: Coordinate reference system (CRS) record Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [Prop] CoordinateSystemName https://admin-shell.io/idta/prop/coordinatesystemname/1/0 coordinate system name [String] 0..1 [Prop] CoordinateSystemId https://admin-shell.io/idta/prop/coordinatesystemid/1/0 Identification of a coordinate system [String] 1 [Prop] CoordinateSystemType https://admin-shell.io/idta/prop/coordinatesystemtype/1/0 Type of a coordinate system with the allowed enumeration values "EPSG:4326" or "LOCAL" [String] 1 [Prop] ElevationReference https://admin-shell.io/idta/prop/elevationreference/1/0 Reference of the elevation information in a coordinate system; with the allowed enumeration values "SEALEVEL" or "LOCAL" [String] 1 [Prop] SeaLevelOfBaseHeight https://admin-shell.io/idta/prop/sealevelofbaseheight/1/0 Sea level of the base height of a coordinate system; normally the base height is at the origin of the coordinate system with Z=0,00 m [Float] 0..1 [SML] GroundControlPoints https://admin-shell.io/idta/sml/groundcontrolpoints/1/0 Arrays containing a mapping between geographic coordinates (longitude, latitude) in WGS84 (EPSG:4326) and relative coordinates (x,y) [] 1 elements 1 3.6. SubmodelElements of SML “GroundControlPoints” Table 6. SubmodelElements of SML “GroundControlPoints” idShort: GroundControlPoints Class: SubmodelElementList semanticId: https://admin-shell.io/idta/sml/groundcontrolpoints/1/0 Parent: CoordinateSystem00 Explanation: Arrays containing a mapping between geographic coordinates (longitude, latitude) in WGS84 (EPSG:4326) and relative coordinates (x,y) Element details: orderRelevant=Yes, semanticIdListElement=[GlobalReference, https://admin-shell.io/idta/smc/groundcontrolpointsentry/1/0], typeValueListElement=SubmodelElementCollection [SME type] idShort semanticId Description@en [valueType] example card. [SMC] GroundControlPoint00 https://admin-shell.io/idta/smc/groundcontrolpointsentry/1/0 An array containing a mapping between geographic coordinates (longitude, latitude) in WGS84 (EPSG:4326) and relative coordinates (x,y) [] 2 elements 3.7. SubmodelElements of SMC “GroundControlPointsEntry Table 7. SubmodelElements of SMC “GroundControlPointsEntry idShort: GroundControlPoint00 Class: SubmodelElementCollection semanticId: https://admin-shell.io/idta/smc/groundcontrolpointsentry/1/0 Parent: GroundControlPoints Explanation: An array containing a mapping between geographic coordinates (longitude, latitude) in WGS84 (EPSG:4326) and relative coordinates (x,y) Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [SMC] GeographicCoordinates 0173-1#02-ABH934#002 [] 2 elements 1 [SMC] RelativeCoordinates 0173-1#02-ABG741#001 Coordinates within a cartisian coordinate system [] 2 elements 1 3.8. SubmodelElements of SMC “GeographicCoordinates” Table 8. SubmodelElements of SMC “GeographicCoordinates” idShort: GeographicCoordinates Class: SubmodelElementCollection semanticId: 0173-1#02-ABH934#002 Parent: GroundControlPoint00 Explanation: Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [Prop] Longitude 0173-1#02-ABH961#002 [Double] 1 [Prop] Latitude 0173-1#02-ABH960#002 [Double] 1 3.9. SubmodelElements of SMC “RelativeCoordinates” Table 9. SubmodelElements of SMC “RelativeCoordinates” idShort: RelativeCoordinates Class: SubmodelElementCollection semanticId: 0173-1#02-ABG741#001 Parent: GroundControlPoint00 Explanation: Coordinates within a cartisian coordinate system Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [Prop] X https://admin-shell.io/idta/prop/x/1/0 X-coordinate value within a coordinate system [Float] 1 [Prop] Y https://admin-shell.io/idta/prop/y/1/0 Y-coordinate value within a coordinate system [Float] 1 3.10. SubmodelElements of SML “VisitedAreas” Table 10. SubmodelElements of SML “VisitedAreas” idShort: VisitedAreas Class: SubmodelElementList semanticId: https://admin-shell.io/idta/sml/visitedareas/1/0 Parent: AssetLocation Explanation: List with areas (e.g., sites, buildings, field warehouses) where an asset has been located or is located Element details: orderRelevant=No, semanticIdListElement=[GlobalReference, https://admin-shell.io/idta/smc/visitedareasrecord/1/0], typeValueListElement=SubmodelElementCollection [SME type] idShort semanticId Description@en [valueType] example card. [SMC] VisitedArea00 https://admin-shell.io/idta/smc/visitedareasrecord/1/0 Areas (e.g., site, building, field warehouse) where an asset has been located or is located [] 9 elements 3.11. SubmodelElements of SMC “VisitedAreasRecord” Table 11. SubmodelElements of SMC “VisitedAreasRecord” idShort: VisitedArea00 Class: SubmodelElementCollection semanticId: https://admin-shell.io/idta/smc/visitedareasrecord/1/0 Parent: VisitedAreas Explanation: Areas (e.g., site, building, field warehouse) where an asset has been located or is located Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [Ref] CoordinateSystemOfArea https://admin-shell.io/idta/ref/coordinatesystemreference/1/0 Reference to a local coordinate reference system for an area [] [Submodel, https://admin-shell.io/idta/smt/assetlocation] 0..1 [SML] AddressReferences https://admin-shell.io/idta/sml/addressreferences/1/0 List with references to addresses for the area (area addresses) [] 1 elements 0..1 [SML] AreaRegionCoordinates https://admin-shell.io/idta/sml/regioncoordinates/1/0 Coordinates forming a polygon that describes the area within the coordinate reference system of the area [] 1 elements 0..1 [Prop] KindOfArea https://admin-shell.io/idta/prop/kindofarea/1/0 Arealart [String] 0..1 [Prop] AreaName https://admin-shell.io/idta/prop/areaname/1/0 Name of the area or building [String] 0..1 [Prop] AreaId https://admin-shell.io/idta/prop/areaid/1/0 Identification of an area [String] 1 [MLP] AreaDesciption https://admin-shell.io/idta/mlp/areadescription/1/0 Description of an area [] Description of an area@en 0..1 [File] AreaLayout https://admin-shell.io/idta/file/arealayout/1/0 File with a layout (map) of the area (e.g., hall plan) [] 0..1 [Prop] BuildingLevel 0173-1#02-ABJ094#001 [String] 0..1 3.12. SubmodelElements of SML ”AreaRegionCoordinates” Table 12. SubmodelElements of SML ”AreaRegionCoordinates” idShort: AreaRegionCoordinates Class: SubmodelElementList semanticId: https://admin-shell.io/idta/sml/regioncoordinates/1/0 Parent: VisitedArea00 Explanation: Coordinates forming a polygon that describes the area within the coordinate reference system of the area Element details: orderRelevant=Yes, semanticIdListElement=[GlobalReference, https://admin-shell.io/idta/smc/regioncoordinateentry/1/0], typeValueListElement=SubmodelElementCollection [SME type] idShort semanticId Description@en [valueType] example card. [SMC] AreaRegionCoordinate00 https://admin-shell.io/idta/smc/regioncoordinateentry/1/0 One coordinate of coordinates forming a polygon that describes the region of the area within the coordinate reference system of the area [] 2 elements 3.13. SubmodelElements of SMC ”RegionCoordinateEntry” Table 13. SubmodelElements of SMC ”RegionCoordinateEntry” idShort: AreaRegionCoordinate00 Class: SubmodelElementCollection semanticId: https://admin-shell.io/idta/smc/regioncoordinateentry/1/0 Parent: AreaRegionCoordinates Explanation: One coordinate of coordinates forming a polygon that describes the region of the area within the coordinate reference system of the area Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [Prop] X https://admin-shell.io/idta/prop/x/1/0 X-coordinate value within a coordinate system [Float] 1 [Prop] Y https://admin-shell.io/idta/prop/y/1/0 Y-coordinate value within a coordinate system [Float] 1 3.14. SubmodelElements of SMC “AssetTraces” Table 14. SubmodelElements of SMC “AssetTraces” idShort: AssetTraces Class: SubmodelElementCollection semanticId: https://admin-shell.io/idta/smc/assettraces/1/0 Parent: AssetLocation Explanation: Collection of localization event records for sites, areas, fences and locations Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [Ref] AreaEventTimeSeriesData https://admin-shell.io/idta/ref/eventtimeseriesdata/1/0 Reference to an AAS time series data Submodel instance of the same AAS with AreaRecords [] [Submodel, https://admin-shell.io/idta/ref/eventtimeseriesdata/1/0] 0..1 [Ref] LocationEventTimeSeriesData https://admin-shell.io/idta/ref/eventtimeseriesdata/1/0 Reference to an AAS time series data Submodel instance of the same AAS with LocationRecords [] [Submodel, https://admin-shell.io/idta/ref/eventtimeseriesdata/1/0] 0..1 [SML] AreaRecords https://admin-shell.io/idta/sml/arearecords/1/0 List with records for area localization events [] 1 elements 0..1 [SML] LocationRecords https://admin-shell.io/idta/sml/locationrecords/1/0 List with records for location (position) localization events [] 1 elements 0..1 3.15. SubmodelElements of SML “AreaRecords” Table 15. SubmodelElements of SML “AreaRecords” idShort: AreaRecords Class: SubmodelElementList semanticId: https://admin-shell.io/idta/sml/arearecords/1/0 Parent: AssetTraces Explanation: List with records for area localization events Element details: orderRelevant=Yes, semanticIdListElement=[GlobalReference, https://admin-shell.io/idta/smc/arearecordsrecord/1/0], typeValueListElement=SubmodelElementCollection [SME type] idShort semanticId Description@en [valueType] example card. [SMC] AreaRecord00 https://admin-shell.io/idta/smc/arearecordsrecord/1/0 Record of an area localization event [] 5 elements 3.16. SubmodelElements of SMC “AreaRecordsRecord” Table 16. SubmodelElements of SMC “AreaRecordsRecord” idShort: AreaRecord00 Class: SubmodelElementCollection semanticId: https://admin-shell.io/idta/smc/arearecordsrecord/1/0 Parent: AreaRecords Explanation: Record of an area localization event Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [Ref] AreaRef https://admin-shell.io/idta/ref/areareference/1/0 Reference to the area where the event has been recorded for [] [Submodel, https://admin-shell.io/idta/smt/assetlocation] 1 [Prop] Time 0173-1#02-ABF198#002 Time when the event occurred [DateTime] 1 [Prop] EventId https://admin-shell.io/idta/prop/eventid/1/0 Identification of an event [String] 0..1 [Prop] ProviderId https://admin-shell.io/idta/prop/providerid/1/0 Identifikation of the location provider which triggered the event [String] 0..1 [Prop] EventType https://admin-shell.io/idta/prop/eventtype/1/0 Type of an event that is triggered when an asset is located at a localization fence [String] 1 3.17. SubmodelElements of SML “LocationRecords” Table 17. SubmodelElements of SML “LocationRecords” idShort: LocationRecords Class: SubmodelElementList semanticId: https://admin-shell.io/idta/sml/locationrecords/1/0 Parent: AssetTraces Explanation: List with records for location (position) localization events Element details: orderRelevant=Yes, semanticIdListElement=[GlobalReference, https://admin-shell.io/idta/smc/locationrecordsrecord/1/0], typeValueListElement=SubmodelElementCollection [SME type] idShort semanticId Description@en [valueType] example card. [SMC] LocationRecord00 https://admin-shell.io/idta/smc/locationrecordsrecord/1/0 Record of a location (position) localization event [] 14 elements 3.18. SubmodelElements of SMC “LocationRecordsRecord” Table 18. SubmodelElements of SMC “LocationRecordsRecord” idShort: LocationRecord00 Class: SubmodelElementCollection semanticId: https://admin-shell.io/idta/smc/locationrecordsrecord/1/0 Parent: LocationRecords Explanation: Record of a location (position) localization event Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [Ref] CoordinateSystemReference https://admin-shell.io/idta/ref/coordinatesystemreference/1/0 Reference to a coordinate reference system for the position [] [Submodel, https://aas-connect.com/smt/data_model_for_asset_location] 1 [SMC] Position 0173-1#02-ABI783#001 Position of the asset [] 3 elements 1 [Prop] ProviderId https://admin-shell.io/idta/prop/providerid/1/0 Identifikation of the location provider which triggered the event [String] 0..1 [Prop] ProviderType https://admin-shell.io/idta/prop/providertype/1/0 Type of the location information provider, e.g. "UWB tag" [String] 0..1 [Prop] Accuracy https://admin-shell.io/idta/prop/accuracy/1/0 The horizontal accuracy of the position data [Double] 0..1 [Prop] MagneticHeading https://admin-shell.io/idta/prop/magneticheading/1/0 The magnetic heading direction of the Asset [Integer] 0..1 [Prop] TrueHeading https://admin-shell.io/idta/prop/trueheading/1/0 The corrected magnetic heading direction of the Asset [Integer] 0..1 [Prop] HeadingAccuracy https://admin-shell.io/idta/prop/headingaccuracy/1/0 The maximum deviation between the reported magnetic heading and the true heading [Integer] 0..1 [Prop] Time 0173-1#02-ABF198#002 The time (timestamp) when the location data was generated (e.g., by a RTLS) [DateTime] 1 [Prop] TransmissionTime https://admin-shell.io/idta/prop/transmissiontime/1/0 Time (timestamp) when the location information has been updated Time (timestemp) when the location information has been updated [DateTime] 0..1 [MLP] LocationDescription https://admin-shell.io/idta/mlp/locationdescription/1/0 Location description (meta information for the position) , it is recommended to refer to the origin of the CRS [] Location description (meta information for the position) , it is recommended to refer to the origin of the CRS@en 0..1 [Prop] Speed 0173-1#02-AAV544#004 Speed of the asset at the time where the position was determined [Float] 0..1 [Prop] Course https://admin-shell.io/idta/prop/course/1/0 The current course ("compass direction") where the asset is heading to [Integer] 0..1 [Prop] ReferencePointId https://admin-shell.io/idta/prop/referencepointid/1/0 Identificator of a reference point at the Asset for which the position has been submitted [String] 0..1 3.19. SubmodelElements of SMC “Position” Table 19. SubmodelElements of SMC “Position” idShort: Position Class: SubmodelElementCollection semanticId: 0173-1#02-ABI783#001 Parent: LocationRecord00 Explanation: Position of the asset Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [Prop] X https://admin-shell.io/idta/prop/x/1/0 X-coordinate value within a coordinate system [Float] 1 [Prop] Y https://admin-shell.io/idta/prop/y/1/0 Y-coordinate value within a coordinate system [Float] 1 [Prop] Z https://admin-shell.io/idta/prop/z/1/0 Z-coordinate (height) value within a coordinate system [Float] 1 3.20. SubmodelElements of SMC “AssetLocatingInformation” Table 20. SubmodelElements of SMC “AssetLocatingInformation” idShort: AssetLocatingInformation Class: SubmodelElementCollection semanticId: https://admin-shell.io/idta/sml/assetlocatinginformation/1/0 Parent: AssetLocation Explanation: Collection with additional information concerning the localization of an asset Element details: - [SME type] idShort semanticId Description@en [valueType] example card. [Prop] Localizable https://admin-shell.io/idta/prop/localizable/1/0 Information wether the position can be currently updated with the correct position [Boolean] 0..1 [MLP] AssetLocationServiceRealTimeCapability https://admin-shell.io/idta/mlp/realtimecapabilityofaas/1/0 Description of the extend and conditions for real time applications of the AAS Description of the extend and conditions for real time applications of the AAS [] Description of the extend and conditions for real time applications of the AAS@en 0..1 [Prop] RealtimeLocationSourceType https://admin-shell.io/idta/prop/realtimelocationsourcetype/1/0 Type or name of the source that delivers real time information for the asset’s location, e.g., OMLOX [String] 0..1 [MLP] RealtimeLocationSource https://admin-shell.io/idta/mlp/realtimelocationsource/1/0 Information regarding a source for real time location data, e.g., URL and API documentation for DeepHub [] Information regarding a source for real time location data, e.g., URL and API documentation for DeepHub@en 0..1 Annex A. Explanations on used table formats 1. General The used tables in this document try to outline information as concise as possible. They do not convey all information on Submodels and SubmodelElements. For this purpose, the definitive definitions are given by a separate file in form of an AASX file of the Submodel template and its elements. 2. Tables on Submodels and SubmodelElements For clarity and brevity, a set of rules is used for the tables for describing Submodels and SubmodelElements. The tables follow in principle the same conventions as in [5]. The table heads abbreviate 'cardinality' with 'card'. The tables often place two informations in different rows of the same table cell. In this case, the first information is marked out by sharp brackets [] form the second information. A special case are the semanticIds, which are marked out by the format: (type)(local)[idType]value. The types of SubmodelElements are abbreviated: SME type SubmodelElement type Property Property MLP MultiLanguageProperty Range Range File File Blob Blob Ref ReferenceElement Rel RelationshipElement SMC SubmodelElementCollection If an idShort ends with '_00_', this indicates a suffix of the respective length (here: 2) of decimal digits, in order to make the idShort unique. A different idShort might be choosen, as long as it is unique in the parent’s context. The Keys of semanticId in the main section feature only idType and value, such as: https://admin-shell.io/vdi/2770/1/0/DocumentId/Id. The attribute "type" (typically "ConceptDescription" and "(local)" or "GlobalReference") need to be set accordingly; see [6]. If a table does not contain a column with "parent" heading, all represented attributes share the same parent. This parent is denoted in the head of the table. Multi-language strings are represented by the text value, followed by '@'-character and the ISO 639 language code: example@EN. The [valueType] is only given for Properties. Bibliography [1] “Recommendations for implementing the strategic initiative INDUSTRIE 4.0”, acatech, April 2013. [Online]. Available https://www.acatech.de/Publikation/recommendations-for-implementing-the-strategic-initiative-industrie-4-0-final-report-of-the-industrie-4-0-working-group/ [2] “Implementation Strategy Industrie 4.0: Report on the results of the Industrie 4.0 Platform”; BITKOM e.V. / VDMA e.V., /ZVEI e.V., April 2015. [Online]. Available: https://www.bitkom.org/noindex/Publikationen/2016/Sonstiges/Implementation-Strategy-Industrie-40/2016-01-Implementation-Strategy-Industrie40.pdf [3] “The Structure of the Administration Shell: TRILATERAL PERSPECTIVES from France, Italy and Germany”, March 2018, [Online]. Available: https://www.plattform-i40.de/I40/Redaktion/EN/Downloads/Publikation/hm-2018-trilaterale-coop.html [4] “Beispiele zur Verwaltungsschale der Industrie 4.0-Komponente – Basisteil (German)”; ZVEI e.V., Whitepaper, November 2016. [Online]. Available: https://www.zvei.org/presse-medien/publikationen/beispiele-zur-verwaltungsschale-der-industrie-40-komponente-basisteil/ [5] “Verwaltungsschale in der Praxis. Wie definiere ich Teilmodelle, beispielhafte Teilmodelle und Interaktion zwischen Verwaltungsschalen (in German)”, Version 1.0, April 2019, Plattform Industrie 4.0 in Kooperation mit VDE GMA Fachausschuss 7.20, Federal Ministry for Economic Affairs and Energy (BMWi), Available: https://www.plattform-i40.de/PI40/Redaktion/DE/Downloads/Publikation/2019-verwaltungsschale-in-der-praxis.html [6] IDTA 01001-3-0: “Specification of the Asset Administration Shell; Part 1 (Version 3.0)”, March 2023, [Online]. Available: https://industrialdigitaltwin.org/wp-content/uploads/2023/06/IDTA-01001-3-0_SpecificationAssetAdministrationShell_Part1_Metamodel.pdf [7] “Semantic interoperability: challenges in the digital transformation age”; IEC, International Electronical Commission; 2019. [Online]. Available: https://basecamp.iec.ch/download/iec-white-paper-semantic-interoperability-challenges-in-the-digital-transformation-age-en/ [8] Common terms and abbreviations according to VDI FA 7.21 Wiki; Available: http://i40.iosb.fraunhofer.de/ [9] United States: US Code of Federal regulations, see https://www.ecfr.gov/current/title-22/chapter-I/subchapter-M/part-120/subpart-C/section-120.42
